AS7100 Radar Rainfall Sensor

AS7100 Radar Rainfall Sensor is a next-generation digital precipitation gauge designed for accurate, maintenance-free rainfall, snow, and hail detection. Using 24 GHz Doppler radar technology, it measures droplet velocity, particle size, and precipitation type in real time. With no moving parts and ultra-low pow

24 GHz Doppler radar for real-time rain, snow, and hail

Key Features



  • Advanced 24 GHz Doppler Radar Technology – precise measurement of rain, snow, and hail

  • High Sensitivity & Fast Response – detects rainfall start and stop instantly

  • Maintenance-Free Design – no moving parts, no clogging, no recalibration

  • All-Weather Operation – works from -40 °C to +70 °C and 0–100 % humidity

  • Compact & Lightweight – Ø140 mm × 96 mm, only 0.65 kg

  • Low Power (< 3 W) – ideal for solar-powered or remote installations

  • Multiple Communication Protocols – RS232/RS485, MODBUS, SDI-12, NMEA0183

Applications



  • Meteorological and environmental monitoring stations

  • Smart city weather networks

  • Flood forecasting and early warning systems

  • Irrigation and water resource management

  • Agricultural and horticultural automation

  • Emergency weather alert systems

Technical Highlights



  • Measurement range: 0–500 mm/hr

  • Resolution: 0.1 mm

  • Accuracy: ±5 % (@ < 5 m/s wind)

  • Power supply: 12–24 V DC

  • Output: RS232 / RS485 (MODBUS-RTU / ASCII / NMEA0183 / SDI-12)

  • Housing: Aluminum Alloy + ABS, IP-rated weatherproof

Our History

Founded in 1995, LABTECH ELECTRONICS PRIVATE LIMITED has been providing quality manufacturing services for over 25 years. We started as a small family-owned business and have since grown to become a leading provider in the industry.

Datasheet

AS7100 RADAR RAIN FALL SENSOR -DIGITAL RAIN GAUGE (pdf)

Download
